3D Abyss & Frosted Dance Floors
Composed of abyss-style and frosted-style panels, when combined they create a rainbow-like effect, offering a rich variety of configurations. Both magnetic and wired connections are available.
Request Product Details
Tell us your target use, quantity plan, and customization needs. Our team will send a tailored quotation and shipping suggestion.
Specifications
| Application | Outdoor Events, Party |
| Type | LED Dance Floor |
| Light Source | LED |
| Control Method | Sound-Activated, Touch Sensor |
| IP Rating | IP67 Waterproof |
| Color | RGB |
| place of origin | Henan, China |
| Customization | OEM/ODM available |
Product Description
It consists of an ABS frame, glass, and LED light strips. The magnetic version has magnets on the edges, making installation and removal very easy, allowing for various shape transformations and featuring a power-off memory function.
Shopping malls, parties, weddings, bars, exhibitions, dances, concerts, and various other entertainment venues.
Shopping malls, parties, weddings, bars, exhibitions, dances, concerts, and various other entertainment venues.
Key Features
1. Abrasion Resistance: Made with 10mm tempered glass, it is very durable and scratch-resistant, even high heels won't damage it.
2. Waterproof Rating: IP67 (drinks and alcohol spills are not a problem). The power supply is equipped with a waterproof protective casing.
3. Extremely Strong Load-Bearing Capacity: Each panel can withstand approximately 600 to 700 kilograms of weight, suitable for car shows.
4. Lifespan: Over 10 years, >100,000 hours.
5. Multiple Control Methods (SD controller + remote control + sound control)
6. The SD card contains 96 modes, including 3D mirroring, RGB gradient changes, jumping effects, rotating effects, rendering effects, chasing effects, and automatic operation functions.
7. Four floor tiles are fixed on one panel, tightly connected and not easy to slide.
8. Slopes are provided on all four sides for anti-slip and safety.
9. Each light strip has 64 5050 LED beads for brighter illumination.
10. The flight case is equipped with accessory slots; everything can be stored in the flight case for convenient transportation
2. Waterproof Rating: IP67 (drinks and alcohol spills are not a problem). The power supply is equipped with a waterproof protective casing.
3. Extremely Strong Load-Bearing Capacity: Each panel can withstand approximately 600 to 700 kilograms of weight, suitable for car shows.
4. Lifespan: Over 10 years, >100,000 hours.
5. Multiple Control Methods (SD controller + remote control + sound control)
6. The SD card contains 96 modes, including 3D mirroring, RGB gradient changes, jumping effects, rotating effects, rendering effects, chasing effects, and automatic operation functions.
7. Four floor tiles are fixed on one panel, tightly connected and not easy to slide.
8. Slopes are provided on all four sides for anti-slip and safety.
9. Each light strip has 64 5050 LED beads for brighter illumination.
10. The flight case is equipped with accessory slots; everything can be stored in the flight case for convenient transportation
LED Dance Floor FAQ
1. How is it connected?
We have 3 connection methods:
Wired, magnetic, and rechargeable magnetic.
Wired: The first row connects to the power supply and controller, and each subsequent tile is wired front and back.
Magnetic: Only one row needs to be connected to the power supply and controller; the other tiles are powered via magnets, requiring no wiring.
Rechargeable magnetic: Built-in controller, no wires needed.
The wired version is more economical and suitable for fixed locations.
The magnetic version is easier to install, convenient to move, and suitable for rental businesses.
2. Is it waterproof? Can it withstand rain?
The waterproof rating is IP65. It's fine if drinks are accidentally spilled on it, as we've added waterproof protective covers to the connections and a protective box to the power supply. However, it cannot be used outdoors in the rain.
3. Is it sturdy? What is the thickness?
Our glass is 1cm thick, and each tile can bear 600-700kg, suitable for car shows.
4. What sizes are most popular?
Most of our customers are in the rental business, and they usually choose 20*20ft or 16*16ft.
This depends on your venue size or how many people you want to accommodate.
If you want to accommodate 100 people, we recommend 144 tiles.
5. What is the power consumption of the floor tiles when working?
Full load: 2000W
Red, green, and blue color changing: 1000W
Single color: 700W
6. Service life:
More than 100,000 hours. Avoid continuous use for 24 hours a day.
7. How long does the rechargeable magnetic version last on a full charge?
It takes 2-3 hours to fully charge, and a full charge lasts about 10 hours. The built-in battery is 6000 mAh.
8. Why do other companies use 12 magnets, while you use 6?
Of the 12 magnets, 6 are for power supply and 6 are for attachment. We added fixing plates to the bottom, which provide better fixing than magnets, so we removed 6 magnets, which also reduces weight.
9. How much does the panel weigh?
50cm single tile: 11kg, 60cm single tile: 14kg
10. Mold and ramp material: Aluminum and ABS differences? Hardness: Aluminum alloy metal and ABS high-strength plastic have the same hardness.
Weight: Aluminum alloy is heavier.
Casting: Aluminum alloy cannot be cast into complex structural components, while ABS plastic can.
Mold Cost: Aluminum alloy molds are less expensive, while ABS plastic molds are more expensive.
11. Ramp dimensions? Can the ramp be customized?
7.2cm Only the wired version can be customized in size, and only stainless steel can be used.
12. Are the magnets easy to replace?
The magnets are almost impossible to break. They can be replaced if necessary, and we will provide you with installation instructions.
13. Why is the wired version more durable yet cheaper than the magnetic version?
Because we use magnets with very high hardness and strong suction, the cost is higher than the cost of the wires.
We have 3 connection methods:
Wired, magnetic, and rechargeable magnetic.
Wired: The first row connects to the power supply and controller, and each subsequent tile is wired front and back.
Magnetic: Only one row needs to be connected to the power supply and controller; the other tiles are powered via magnets, requiring no wiring.
Rechargeable magnetic: Built-in controller, no wires needed.
The wired version is more economical and suitable for fixed locations.
The magnetic version is easier to install, convenient to move, and suitable for rental businesses.
2. Is it waterproof? Can it withstand rain?
The waterproof rating is IP65. It's fine if drinks are accidentally spilled on it, as we've added waterproof protective covers to the connections and a protective box to the power supply. However, it cannot be used outdoors in the rain.
3. Is it sturdy? What is the thickness?
Our glass is 1cm thick, and each tile can bear 600-700kg, suitable for car shows.
4. What sizes are most popular?
Most of our customers are in the rental business, and they usually choose 20*20ft or 16*16ft.
This depends on your venue size or how many people you want to accommodate.
If you want to accommodate 100 people, we recommend 144 tiles.
5. What is the power consumption of the floor tiles when working?
Full load: 2000W
Red, green, and blue color changing: 1000W
Single color: 700W
6. Service life:
More than 100,000 hours. Avoid continuous use for 24 hours a day.
7. How long does the rechargeable magnetic version last on a full charge?
It takes 2-3 hours to fully charge, and a full charge lasts about 10 hours. The built-in battery is 6000 mAh.
8. Why do other companies use 12 magnets, while you use 6?
Of the 12 magnets, 6 are for power supply and 6 are for attachment. We added fixing plates to the bottom, which provide better fixing than magnets, so we removed 6 magnets, which also reduces weight.
9. How much does the panel weigh?
50cm single tile: 11kg, 60cm single tile: 14kg
10. Mold and ramp material: Aluminum and ABS differences? Hardness: Aluminum alloy metal and ABS high-strength plastic have the same hardness.
Weight: Aluminum alloy is heavier.
Casting: Aluminum alloy cannot be cast into complex structural components, while ABS plastic can.
Mold Cost: Aluminum alloy molds are less expensive, while ABS plastic molds are more expensive.
11. Ramp dimensions? Can the ramp be customized?
7.2cm Only the wired version can be customized in size, and only stainless steel can be used.
12. Are the magnets easy to replace?
The magnets are almost impossible to break. They can be replaced if necessary, and we will provide you with installation instructions.
13. Why is the wired version more durable yet cheaper than the magnetic version?
Because we use magnets with very high hardness and strong suction, the cost is higher than the cost of the wires.
